Dominic P. Guaņa
organicchemistry_01@yahoo.com.ph
I am studying the interaction of urea molecule and nickel atom, i have performed a potential energy scan around the oxygen atom in urea, i have allowed the nickel atom to rotate around it from 90 to 180 degrees, 90 degree from urea's axis of symmetry to 180 degree.
I am expecting that energy will be lower at 180 degree but unexpectedly it is somewhere between 90 to 180 and not even close to 180.
Attach is the image of energy curve of expected result and rsurface result. Need help for this.
Bellow is the input file used.
!============== SCFTYP, NZVAR, MAXIT & SYSTEM ==============
$CONTRL
!EXETYP=CHECK
SCFTYP=UHF
NZVAR=21
MAXIT=10000
$END
$SYSTEM
MWORDS=50
TIMLIM=10000
FASTF=.T.
WSCTL=.T.
L2SIZE=1750
$END
!============== Run Type ==============
$CONTRL
RUNTYP=RSURFACE
$END
!============== DLC ==============
!-- Automatic generation of internal coordinates --
$ZMAT
DLC=.T.
AUTO=.T.
$END
$STATPT
NOREG=5
NSTEP=200
ITBMAT=50
$END
!============== Functional ==============
$CONTRL
DFTTYP=B3LYP
$END
!============== Basis ==============
$BASIS
GBASIS=TZV
NPFUNC=1
NDFUNC=1
NFFUNC=1
$END
!============== NONVDW ==============
!-- User defined bond/s --
$ZMAT
NONVDW(1)=1,9
$END
!============== SURFACE ==============
$SURF
NDISP1=11
DISP1=8.98999999
$END
$ZMAT
IFZMAT(1)=2,2,1,9,1,1,9
SCAN=.T.
IFDMOD=2
AUTOFV=.T.
$END
!============== Geometry ==============
$DATA
Method Proper, Urea, Nickel, Symmetry, RSURFACE
Cs
0.0 1.0 0.0 0.0 0.0 0.0
0.0 0.0 1.0
O 8.0 0.00000000 0.00000000 0.00000000
C 6.0 0.00000000 1.21811247 0.00000000
N 7.0 1.16005301 1.95553017 0.00000000
H 1.0 2.02442145 1.44599521 0.00000000
H 1.0 1.18871176 2.95830655 0.00000000
Ni 28.0 0.00000000 0.00000000 20.00000000
$END
expected and rsurface result
